Light weight muffle furnace (EIE – 107)

Standard Model (EIE – 107D)

Inner Chamber made of Ceramic material with Muffle pattern for heating elements & Outer body is fabricated from CRC Sheet, Powder coated in attractive shades

GMP Model (EIE – 107DG)

Inner Chamber made of Ceramic material with muffle pattern for heating elements & Outer body is fabricated from S.S.304 matt finished material.

Applications

Particle size distribution

Salient Features

  • Ceramic fiber wool insulation to reduce weight and size of furnace.
  • Less heat up time is
  • Nominal heat-loss resulting in power saving
  • Built in vent port for removal of noxious gases etc.
  • Provision of hole with cover in the furnace door to insert temp sensor for calibration purpose
  • Construction : CRC sheet - attractively powder coated
  • Max Temperature : 1000°C
  • Working Temperature : 900°C
  • Temperature control : Dual display microprocessor based Digital temperature indicator cum controller
  • Temperature Sensor : K - type sensor
  • Heating elements : KANTHAL A-1 wire in coil form placed in the Elements ribs & easily replaceable
  • Circuit Wiring : As per CE Norms
  • Operation on : 220/230 Volts, Single phase, AC Supply
  • Available in following sizes

Selection Guide

Inner chamber size (mm) (H x W x D) Power consumption (Kw) Approximate Weight (Kgs) Digital Model Numbers (EIE-107DP) Digital GMP Model Numbers (EIE-107DG)
225 x 100 x 100 (9” x 4” x 4”) 1.5 60 EIE-107DP2.25 EIE-107DG2.25
250 x 125 x 125 (10” x 5” x 5”) 2.0 71 EIE-107DP4 EIE-107DG4
300 x 150 x 150 (12” x 6” x 6”) 3.0 82 EIE-107DP7 EIE-107DG7
300 x 200 x 200 (12” x 8” x 8”) 5.0 115 EIE-107DP12 EIE-107DG12
450 x 225 x 225 (18” x 9” x 9”) 6.0 125 EIE-107DP23 EIE-107DG23

D : Digital   |   G : GMP   |   P : Powder coating
