CoolingChamber - EIEPHARMA

Cooling Chamber (EIE – 117)

Standard Model (EIE – 117DP)

Inner Chamber made of mirror Polished Stainless Steel (S.S.304) material & Outer body with CRC Sheet powder coated in attractive shades

GMP Model (EIE – 117DG)

Inner Chamber made of mirror Polished Stainless Steel (S.S. 316) material & Outer body with Matt finished S.S. 304 Material

Optional accessories at extra cost

  • 21-CFR Compliance software with PC Communication
  • Highly advanced HMI & PLC Control system
  • GSM Alert through SIM Card
  • Data logger with 4 temperature + 4 Humidity sensors
  • Spare PT-100 Sensor for validation purpose
  • Standby Refrigeration System
  • Biometrics Magnetic Door Access for Secured Door opening with software to maintain log
  • On-Site Validation (mapping) for 24 hours on Empty, Half and Full load condition

Cooling chamber selection guide

Inner chamber size (cms) (D x W x H) Overall dimensions (cms) (D x W x H) No of trays Chamber capacity (Liters) Power consumption (Kw) Approximate Weight (Kgs) Digital Model Numbers (EIE-117DP) Digital GMP Model Numbers (EIE-117DG)
30 x 30 x 30 52 x 45 x 64 1 27 1.0 45 EIE-117DP27 EIE-117DG27
35 x 35 x 35 57 x 50 x 72 1 64 1.0 52 EIE-117DP64 EIE-117DG64
45 x 45 x 45 67 x 60 x 82 2 92 1.5 98 EIE-117DP92 EIE-117DG92
45 x 45 x 60 67 x 60 x 97 2 121 1.5 115 EIE-117DP121 EIE-117DG121
60 x 60 x 60 82 x 75 x 97 3 216 2.0 135 EIE-117DP216 EIE-117DG216
60 x 60 x 90 82 x 75 x 125 3 324 2.5 175 EIE-117DP324 EIE-117DG324
60 x 60 x 125 82 x 75 x 160 3 450 3.0 240 EIE-117DP450 EIE-117DG450

D : Digital   |   P: Powder coating   |   G: GMP
