BOD Incubator (EIE – 202)

Standard Model (EIE – 202DP)

Inner Chamber made of mirror Polished Stainless Steel (S.S.304) material & Outer body with CRC Sheet powder coated in attractive shades

GMP Model (EIE – 202DG)

Inner Chamber made of mirror Polished Stainless Steel (S.S. 316) material & Outer body with Matt finished S.S. 304 Material

Applications

Used for Media Preparation & Culture growth at temperatures of 22.5°C (±2.5°C) & 32.5°C (± 2.5°C) in Microbiology or ARD labs across the world.

Technical Specifications

  • Construction : Double walled
  • Interior : S.S. - 304 Grade mirror polished Stainless steel material
  • Exterior : Powder coated mild steel material
  • Thermal Insulation : PUF insulation
  • Insulation thickness : 70 mm
  • Temperature Range : 5 °C to 60 °C
  • Illumination : Fluorescent Tube light
  • Fluorescent light watts : 11 Watts
  • Heating source : U-shaped S.S. Tubular heaters
  • Refrigeration : CFC free EMERSON compressor utilizing R-134a ecofriendly refrigerant
  • Observation : Inner transparent acrylic door for quick viewing and retrieval
  • Door lock : Ergonomic and secured key lockable door lock
  • Feet on : Castor wheels (For easy mobility)
  • Electrical : 230 Volt, 15A, 50 Hz, AC Supply
  • Supplied complete with Calibration certificate , IQ-OQ-PQ Documents and test report
  • Calibration certificate with NPL Traceability for temperature sensor and Digital controller

Trays for samples

  • Removable Perforated/S.S. Bar trays
  • Can withstand heavy load
  • Offer better air circulation

Safety Features

  • High temperature safety cut off (Thermostat)
  • Electrical overload cut off (Fuse 10 Amp)
  • Time delay for compressor switch ON

Technical Specifications

Inner chamber size (cms) (D x W x H) Overall dimensions (cms) (D x W x H) No of trays Chamber capacity (Liters) Power consumption (Kw) Approximate Weight (Kgs) Digital Model Numbers (EIE-202DP) Digital GMP Model Numbers (EIE-202DG)
30 x 30 x 30 52 x 45 x 64 1 27 1.0 45 EIE-202DP27 EIE-202DG27
35 x 35 x 35 57 x 50 x 72 1 64 1.0 52 EIE-202DP64 EIE-202DG64
45 x 45 x 45 67 x 60 x 82 2 92 1.5 72 EIE-202DP92 EIE-202DG92
45 x 45 x 60 67 x 60 x 97 2 121 1.5 78 EIE-202DP121 EIE-202DG121
60 x 60 x 60 82 x 75 x 97 3 216 2.0 110 EIE-202DP216 EIE-202DG216
60 x 60 x 90 82 x 75 x 125 3 324 2.5 148 EIE-202DP324 EIE-202DG324

D: Digital   |   P: Powder coating   |   G: GMP

Optional accessories at extra cost

  • 21-CFR Compliance software with PC Communication
  • Highly advanced HMI & PLC Control system
  • GSM Alert through SIM Card
  • Data logger with 4 temperature sensors
  • Spare PT-100 Sensor for validation purpose
  • Standby Refrigeration System
  • On-Site Validation (mapping) for 24 hours on Empty, Half and Full load condition
