Waterbath Incubator Shaker (Shaking Waterbath)

Inner Chamber made of mirror Polished Stainless Steel (S.S.304) material & Outer body with CRC Sheet powder coated in attractive shades

Inner Chamber made of mirror polished Stainless Steel (S.S.316) material & Outer body is fabricated from S.S.304 matt finished material.

For procedure requiring constant shaking, uniform temperature & controlled atmosphere

Construction : Double walled
Inner chamber : Polished stainless steel material S.S. - 304 grade
Exterior body : Fabricated from Mild steel material
Paint : Powder coating
Insulation : Glass wool insulation to prevent direct thermal heat loss
Temperature Range : From 5 °C above ambient to 99 °C
Heating : Open type Air heaters placed at the bottom of the inner chamber.
Temperature controller : Microprocessor based Auto-Tune PID Digital Temperature controller cum indicator
Temperature Stability : ± 0.5 °C
Temperature accuracy : ± 0.5 °C
Heater control : By control switch installed in the control panel
Heater Status : Control indication lamp
Shaking : Achieved by PMDC Geared Motor
Motor RPM : 40-150 RPM
Motor speed display : Digital RPM Indicator (Optional)
Speed control : By electronic Speed Regulator
Shaking racks material : Stainless steel material S.S. - 304 Grade
Bath chamber Size : 15” x 16” x 8” cm /20” x 18” x 8”(W x D x H)
Bath Volume : 30 Liters
Power consumption : 02 KW
Operates on : 230 Volts, 50 Hz, Single phase, AC Supply
Supplied complete with Top Stainless Steel Pyramidal Lid

Digital/Powder coated Model No	Digital/GMP Model No	To hold capacity
EIE-405DP6	EIE-405DG6	6 flasks of 100 ml
EIE-405DP12	EIE-405DG12	9 flasks of 250 ml
EIE-405DP24	EIE-405DG24	16 flasks of 250 ml
EIE-405DP30	EIE-405DG30	18 flasks of 250 ml
